27
Door Jamb
2
9370
(QTY: 8)
(QTY: 4)
Bolt must go thru back side of Panel
or they may interfere with Door action.
Acorn nut should be visible from outside building.
You will need for this page:
Step 9: Door Jambs
Leave these holes open.
Secure Door Jambs with two (2)
screws in the top and bottom of each
Panel as shown.
Leave the holes in the center of each
Door Jamb open as shown below.
Insert two (2) bolts and nuts into the
back side of each Panel as shown
below. Secure the bolts with both a
standard nut and an acorn nut.
27BH
