30
(QTY: 3)
Gable Brace
1
6635
Gable must fi t UNDER Side Wall Angle at corner.
Use bolts where Angles overlap.
Attach Brace with bolt through
bottom hole only.
You will need for this page:
Step 11: Continued
Working with one Gable at a time,
attach the Rear Gables to the Rear
Wall Angle with screws.
To secure Gables together, position
the Gable Brace as shown and
insert a single bolt and nut through
the bottom hole only.
Insert two (2) bolts and nuts where
Wall Angles overlap.
(QTY: 8)
30BH
To Next Page
