Arrow NP10867 - Page 8

6
1 3719 Door Handle Brace 2
2 6635 Gable Brace 2
3 9365 Front Wall Channel 2
4 10497 Horizontal Door Brace 4
5 5986 Rear Wall Angle 2
6 6000 Right Gable 2
7 6001 Left Gable 2
8 6403 Door Track Splice 1
9 6529 Roof Panel 2
10 7483 Roof Panel 4
11 8468 Right Roof Panel 2
12 8469 Left Roof Panel 2
13 8485 Left Side Roof Trim 2
14 8486 Ridge Cap 1
15 10470 Roof Beam 8
16 8836 Right Side Roof Trim 2
17 8839 Side Wall Angle 4
18 8840 Ridge Cap 1
19 8934 Ramp 1
20 8936 Rear Floor Frame 2
21 8937 Side Floor Frame 4
22 6627 Wall Panel 6
23 6300 Vertical Door Brace 2
24 10477 Door 2
25 8471 Corner Panel 4
26 8200 Wall Panel 4
27 9366 Door Track 2
28 9367 Front Floor Frame 2
29 9370 Door Jamb 2
30 9374 Front Wall Panel 2
31 9917 Rear Wall Channel 2
32 9922 Side Wall Channel 4
33 69835 Edge Trim (Green) 4
Key
No.
Part No.
Part Description
Qty.
List
PARTS LIST...
8
08BH
Selected End Views by Key No.
15
33
2
14
4
13
1 3
5
23
8
19 20&21
27 2928
16 17
18
31&32
Gables, Roof Panels, Wall
Panels, and Doors not
shown.
