5400 Series TECSource User’s Manual · Page 11
Interlock Connector
The Interlock connector is a 2-pin Phoenix socket with the following pin-out:
Pin Description
1 Interlock
2 Interlock Ground
Interlock Connector (2-Pin Phoenix)
See Using the Interlock below for additional information.
USB Connector
The USB connector is a standard Type B female connector, and can be plugged
into any USB 1.1 or USB 2.0 port. For more information on using the USB
interface, see the Computer Interfacing Manual which is included on the CD that
accompanied this product.
RS232 Connector
The RS232 connection is male DB-9 connector wired in a NULL modem
configuration.
Pin
Description
2
Receive
3
Transmit
5
Ground
1,4,6
Commoned together
7,8
Commoned together
9
No connection
Shell
Earth ground
RS232 Connector (DB-9 Male)
For more information on using the RS232 interface, see the Computer Interfacing
Manual which is included on the CD that accompanied this product.
