Page 32 · 5400 Series TECSource User’s Manual
Out Off Menu
The entries in the Out Off Menu are there to control which conditions of the
temperature controller will turn off the output. The following conditions are listed,
along with their defaults:
Thi Limit (default Yes)
Tlo Limit (default Yes)
Sensor Open (default Yes)
Sensor Short (default Yes)
Apply Nonactive (default No)
Apply Aux (default No)
R Limit (default No)
Out of Tol (default No)
ITE Limit (default No)
TEC Open (default Yes)
For each condition, if the menu item is set to Yes and the condition is detected,
the output will be shut off.
Temperature limits are a special case due to the multiple sensor inputs. There
are two menu items that control how the temperature limits are applied, Apply
Nonactive and Apply Aux. See Applying Sensor Limits below for more details
on these settings.
