5400 Series TECSource User’s Manual · Page 51
Specifications
All values relate to a one-hour warm-up period.
Description
5400-15-28 5400-30-28 5400-20-56
Drive Channel
Current
Range (A) 15 30 20
Compliance Voltage (V) 28 28 56
Max Power (W) 420 840 960
Resolution (A) 0.01 0.01 0.01
Accuracy (±[% set point + A]) 0.5 + 0.01 0.5 + 0.01 0.5 + 0.01
Noise/Ripple (mA, rms) < 20 < 30 < 25
Temperature Control
Range (°C)
1
-99 to 250
Resolution (°C) 0.001
2
Thermistor Accuracy (±°C)
3
0.05
4
AD560 Accuracy (±°C)
3
0.05
LM335 Accuracy (±°C)
3
0.05
RTD Accuracy (±°C)
3
0.05
Short Term Stability (1hr) (±°C)
5
0.004
Short Term Stability (24hr) (±°C)
5
0.01
Measurement Channels
Current
Resolution (mA) 10
Accuracy (±[% reading + mA]) 0 + 30 0 + 60 0 + 30
Voltage
Resolution (mV) 10
Accuracy (±[% reading + V]) 0 + 0.05
Sensor
6
10μA Thermistor
Range (kΩ) 0.1 – 450
Resolution (kΩ) 0.01
Primary Accuracy (± [% read + kΩ]) 0.05 + 50
Aux Accuracy (± [% read+ kΩ]) 0.20 + 50
100μA Thermistor
Range (kΩ) 0.05 – 45
Resolution (kΩ) 0.001
Accuracy (± [% reading + kΩ]) 0.05 + 5
1
Software limits. Actual range dependent on sensor type and system dynamics
2
RTD and auxiliary sensor resolution 0.01°C
3
Accuracy figures are the additional error the 5400 adds to the measurement, and does not include the
sensor uncertainties.
4
25°C, 100μA thermistor
5
Stability measurements done at 25°C using a 10kΩ thermistor on the 100μA setting. The number is ½
the peak-to-peak deviation from the average over the measurement period.
6
Specifications apply to both primary and auxiliary sensors unless otherwise indicated.
