Description
5400-15-28 5400-30-28 5400-20-56
LM335
Bias (mA) 1
Range (mV) 1730 – 4250
Resolution (mV) 0.1
Accuracy (±[% reading + mV]) 0.3 + 1
AD590
Bias (V) 4.5
Range (μA) 173 – 473
Resolution (μA) 0.01
Accuracy (± [% reading + μA]) 0.03 + 0.1
RTD
Range (Ω) 20 – 192
Resolution (Ω) 0.01
Accuracy (± [% reading + Ω]) 0.03 + 0.1
Current Limit
Resolution (A) 0.1
Accuracy (±A) 0.2
Other
Fan Supply 4 – 12V, 350mA max
Relay Limits 30VDC, 1A max
TEC Connector Female 17W2
Display Type 4x20 VFD
Computer Interface USB 2.0 Full Speed and RS-232 (DB-9, male)
Power
90 – 240 V, 50/60 Hz
600W 1100W 1100W
Size (H x W x D) [inches (mm)] 3.5 (90) x 12 (305) x 14 (356)
Weight [lbs (kg)] 11.6 [5.3]
Operating Temperature +10°C to +40°C
Storage Temperature -20°C to +60°C
