Page 50 · 5400 Series TECSource User’s Manual
0
4
8
12
16
20
24
28
0 5 10 15 20 25 30
TECVoltage(Volts)
TECCurrent(Amps)
SafeOperatingRangefor5400‐30‐28TECSource
Example:
At25A,theminimumvoltageattheTECconnectormust
begreaterthan~8V.Anythingless,andtheinstrument
willlowerthecurrenttostayabovetheredline.
OperatingZone
Anycombinationofcurrentand
voltagethatliesabovethered
lineisacceptable.
Non‐OperatingZone
TECcurrentwillbelimitedif
operatingbelowtheredline.
