Artesis AMT Toolkit - Alarm Conditions

Appendices
51
Error
Number
Error type
Description
error
7.1.2. Alarm Conditions
Alarm
Number
Alarm type
Description
0x0001
Voltage balance
Voltage phase imbalance exceeds the set
threshold
0x0002
Current balance
Current phase imbalance exceeds the set
threshold
0x0004
Voltage range Ch1
Voltage greater than the upper threshold
0x0008
Voltage range Ch2
Voltage greater than the upper threshold
0x0010
Voltage range Ch3
Voltage greater than the upper threshold
0x0020
No voltage Ch1
Voltage less than acceptable (No voltage) limit
0x0040
No voltage Ch2
Voltage less than acceptable (No voltage) limit
0x0080
No voltage Ch3
Voltage less than acceptable (No voltage) limit
0x0100
High current Ch1
Current exceeds upper threshold limit
0x0200
High current Ch2
Current exceeds upper threshold limit
0x0400
High current Ch3
Current exceeds upper threshold limit
0x0800
Motor not running
All currents were measured below their
acceptable (No current) limits
0x1000
Motor connection
fault
One or more currents were measured below their
acceptable limits
0x2000
Line fault
One or two voltage phases were compatible with
zero (below No voltage limit)
0x4000
Power fault
All the voltage phases were compatible with zero
(below No voltage limit)
0x8000
Unstable line
The power lines were not sufficiently stable to
allow the algorithm to obtain data (amplitude and
frequency variations of current and voltage were
excessive)
0x10000
General fault
General fault consisting of one or more of:
No data obtained, no zero crossings detected,
perfect phase balance (voltage or current)
0x20000
Phase ordering
The phase ordering used by AMU is incorrect and
must be rectified.
0x40000
Phase fault
Voltage phase angles incompatible with 120º
