1.6.3. Individual Outs
There are dedicated 3.5mm output jacks for several of the instruments on the rear panel:
• Kick
• Snares (shared by Snare 1 and Snare 2)
• Hi Hats (shared by the Closed and Open Hats)
• FM Drum
When a cable is connected to one of the individual outputs, that instrument will be removed
from the Mix Output and the Headphones. In the case of instruments that share a channel,
such as the Closed and Open Hats, both instruments will be removed from the Mix Output
upon insertion of the cable.
The output level of each instrument channel is set by the corresponding Level knob on the
front panel.
♪: The Distortion does not affect the individual outs. However, there is an independent Drive effect
for the Kick that can be added using the Color feature. This effect is available at the independent Kick
output. See the Color mode section [p.34] for more information.
19 Arturia - User Manual DrumBrute Impact - Overview
