1000Base-X (SFP) Ports
The 7030 is equipped with eight 1000Base-X dual media ports for fiber connectivity only and are intended
for use with Aruba SFPs (mini-GBICs).
Dual-Media Port LEDs
Each pair of Dual-Media ports is equipped two LEDs that allow you to monitor the status of and activity on
the port. These LEDs provide basic monitoring of the status, activity, and basic configuration of each port.
The behavior of the STATUS LED can be changed using the LCD.
LINK/ACT: on the left side of the port, displays the link status of the port.
Status: on the right side of the port, displays the status of the port. The information displayed by this
LED changes based on LCD’s mode. The LED behavior for each mode is describe in Table 5 and Table 6.
Aruba tests and supports Aruba optics within their controller systems. Third party optics are not tested or
supported; therefore, Aruba does not guarantee proper functionality of third party optics when used in an Aruba
system.
Table 4 10/100/1000Base-T Port LEDs
LED Function LCD Mode Indicator Status
LINK/ACT Link status N/A Green (Solid) Link has been established
Green (Blinking) Port is transmitting or
receiving data
Off No link
Status Port status Administrative Green (Solid) Port Enabled
Off Port Administratively
Disabled
Duplex Green (Solid) Full-duplex
Off Half-duplex
Speed Green (Solid) 1000 Mbps
Off 10/100 Mbps
Table 5 1000Base-X Port LEDs
LED Function LCD Mode Indicator Status
LINK/ACT Link status N/A Green (Solid) Link has been established
Green (Blinking) Port is transmitting or
receiving data
Off No link
