3
DC input: Please use the power adaptor comes with the package, using other power adaptor might
damage the device.
Speaker out banana plug: For connection to 4-8ohm passive speakers.
Line input connector: For connection to device with line output.
Subwoofer output connector: For connection to active subwoofer.
Optical input connector: For connection to device with optical output.
USB Type-A port: For connection to USB disk drive.
USB Type-C port: For connection to PC.
BT Antenna: For Bluetooth connection.
Reset button: When in Bluetooth Receiver mode, press twice to disconnect all Bluetooth connections.
Press and hold the button to do factory reset.
5.
6.
7.
8.
9.
10.
11.
12.
13.
5 6 7 8 9 10 11 12 13
