7.2 Adjusting the gas pressure:
1. Turn the gas valve knob to the OFF position.
2. Remove the pressure tap plug.
3. Screw the fitting for a gas pressure measuring device into the pressure tap hole.
4. Place the gas valve knob in the ON position, then turn the fryer on. When the burner lights and
continues to burn, note the gas pressure and compare it to the pressure listed on the fryer rating plate.
5. If necessary, adjust the burner gas pressure by removing the cap from the gas valve regulator and
turning the adjustment screw until the indicated pressure is equal to the pressure listed on the fryer
rating plate. Replace the regulator cap.
6. Turn the fryer off and place the gas valve knob in the OFF position.
7. Remove the fitting from the pressure tap hole and reinstall the pressure tap plug.
drawing A
E) Gas Valve Selection knob PILOT position,
drawing B
F) Gas Valve Selection knob ON position,
drawing C
