Asco C1000 User Manual

Chapter 2 Installation and Wiring 9
Series 230 Automatic Transfer Switch C1000 Intelligent Controller User Manual
2.2 Controller Interface
2.2.1 Controller Interface
C1000 Connector Labels as shown in Fig 2-6
Figure 2-6 C1000 Controller Interfaces
Pin definition as table 2-1, table 2-2 and table 2-3
System Port
User Port
System Port
Reserved
RS485
Port
X2
X3
X1
