2 Chapter 1 Overview
Series 230 Automatic Transfer Switch C1000 Intelligent Controller User Manual
 When there are abnormalities with both Source I and Source II, the transfer switch will transfer the load to the
center-off position to protect the load from getting damaged.
 Built in abnormal transfer diagnosis capabilities in order to protect the transfer switch.
 Many settable options, including over/under voltage, over/under frequency for both sources, and switching time
delays.
 Configurable DI / DO Ports
1.3 Technical Parameters
Application conditions requirements of C1000 Controller as shown in Table 1-1.
Table 1-1 Application Conditions of C1000
Requirement Condition Standards
Temperature
Operating temperature
－
20
℃～＋
60
℃
IEC61800-1 Storage temperature
－
40
℃～＋
70
℃
Temperature change
5
℃
/min
Humidity
95
％
, No condensation
IEC60721-3-3 3K3
Altitude 2000m or less IEC60721-3-3 3K3
Vibration
5~9
，
9~200Hz
，
3.5mm
，
10m/s2
，
5sweep cycles,1oct/min
IEC60721-3-3 3M4
Shock
Sinusoidal
，
15g,6ms
，
3 times/direction
IEC60721-3-3 3M4
Technical parameters of C1000 controller as shown in Table 1-2
Table 1-2 Technical Parameters of C1000 controller
Item Parameter
Rated Operating Voltage
（
Ue
）
2 Pole
：
220Vac (L-N) / 230Vac (L-N) / 240Vac (L-N)
3 Pole / 4 Pole
：
380Vac (L-L) / 400Vac (L-L) / 415Vac (L-L)
Operating Voltage Range
Ue = 220V / 230V / 240V / 380V / 400V
（
0.7
～
1.2
）
x Ue
Ue = 415V
（
0.7
～
1.15
）
x Ue
Rated Operation frequency 50Hz / 60Hz
Rated insulation impulse withstand voltage 6kV
Protection class of enclosure IP20
Pollution degree 3
Overvoltage class Distribution level, Industral conditions.
Lightning tolerability level
Impulse voltage waveform: 10 / 700µs, 5kV 10 times
Impulse voltage waveform: 8 / 20
µ
s, 20kA 1 time
Detectable range and accuracy of C1000 controller are shown in Table 1-3.
Table 1-3 Detect Range and Detect Accuracy
Signal to be Detected Accuracy Detectable Range Remarks
AC Voltage
±3
％
2 pole: 154Vac ~ 288Vac
Share the sampling port with the power input port.
3 Pole / 4 Pole: 266Vac~478Vac
AC Frequency
±1
％
45Hz ~ 65Hz
Electromagnetic interference performance parameters of C1000 controller:
Table 1-4 Electromagnetic Interference Performance Parameters
Item Requirements Standard
Conducted disturbance emission Class A EN 55022
Radiation distubance emission Class A EN 55022
Harmonic current emission Class A EN61000-3-2
Voltage fluctuations and flicker Class A EN61000-3-3
