11
Customer Care Center 1-800-898-1879 www.askousa.com
1
2
3
4
5
When the cabinet is connected to the vent
duct, the entire room is ventilated through
the drying cabinet.The vent duct valve is
replaced with an adapter (not supplied). See
also the section “Ventilation connection”,
on page 18.
Do not assemble the valve which may
already exist in the building in the
ventilation system, inside the drying
cabinet.
This connection provides best drying
results.
The drying cabinet connected to vent duct.
Permanently connected to vent duct
1. Moist air
2. Adapter
3. Hose (maximum 3 ¼ ft (1 m)
in length
4. Exhaust collar
5. Air intake
