Connection to a vent duct
The drying cabinet can be connected to a vent duct in two ways:
By means of a draft stabilizer
The vent duct valve is replaced with the sup-
plied draft stabilizer. See also the section
“Ventilation connection”, on page 18.
The length of the hose for ventilation in sup-
plied kit (only certain markets) is 3
1
/
4
ft (1
m)
Do not assemble the valve which may
already exist in the building in the
ventilation system, inside the drying
cabinet.
When the cabinet is on, 45 m³ (1590 cubic
ft) of moist air is discharged per hour.
Because of this, make sure that air can
enter the room to replace the moist air that
has been removed.
The drying cabinet may not be
connected to a furnace duct.
The drying cabinet connected to vent duct
with a draft stabilizer.
1. Moist air
2. Hose (maximum 3 ¼” ft (1 m) in
length
3. Exhaust collar
4. Draft stabilizer
5. Air intake
