27
Customer Care Center 1-800-898-1879 www.askousa.com
Technical data
Capacity: About 7 1/2 lbs (3.5 kg) of laundry (cotton)
Dewatering capacity: 0.56 ounce/min (16 gram/min)
Electrical connection: Single-phase, 120 V, 60 Hz
Motor: 43 W
Heating element output: 1200 W
Overheating protection: Yes
Time switch: Adjustable up to 4 hours
Hanging length: 630 in. (16 meters)
Dimensions: Height 68” (173.0 cm) Adjustable 67
3
/
4
” - 68
3
/
4
”
(172.0 cm - 174.5 cm)
Width 23
7
/
16
” (59.5 cm)
Depth 24” (61.0 cm)
Weight: About 133 lbs (60 kg)
Color: White or Titanium
Noise level: Max. 58 dB(A)
Energy consumption and drying times
Drying spun-dried wash *)
Setting Energy consumption Drying time Heat
Low 0.33 kWh/lb (0.72 kWh/kg) laundry About 210 min. 45°C (113°F)
Normal 0.34 kWh/lb (0.75 kWh/kg )laundry About 130 min. 65°C (149°F)
Manufacturing standards
See the cabinet’s rating plate
*) The values can vary depending on spin dry speeds.
Installation spacing for custom cabinetry
For built-in installation, minimum ventilation openings in the top and between the cabinet and
the rear wall must be ½” (13 mm).
Exhaust
When the drying cabinet is working, 45 m³ of moist air are evacuated per hour. This air is
taken from the room where the unit is installed.
Technical characteristics
