Level drying cabinet
1. Check to make sure the unit is level front
to back and side to side.
2. Use the supplied Allen wrench and adjust
all four adjustment pads through the holes
in the drying cabinet’s bottom plate (use
pliers if necessary).
3. Press the four cover plugs into the holes.
1. Level
2. Allen wrench
Attaching drying cabinet to wall
Risk for forward tipping
The cabinet may not be used without
being screwed to the wall.
If this is not observed, serious personal
injury and damage can occur.
Warning!
1. Place the drying cabinet in its intended
place, open the door and pull out the upper
hanger section.
2. Drill assembly holes in the wall for the
attachment screws through the predrilled
holes in the back of the drying cabinet.
3. Secure the cabinet with the supplied
screws and associated washers. Fit the
plastic plugs (if necessary) into the wall
and also place the plastic spacers be-
tween the back side of the drying cabinet
and the wall behind it, according to the
figure.
1. Pre-drilled holes
2. Retaining screws with washers
3. Plastic plug
4. Wall behind the drying cabinet
5. Spacer
6. Drying cabinet back wall
