1
Ventilation connection
If the drying cabinet is installed in a
custom cabinetry, fit the exhaust collar
through the vent opening in the upper
part of the cabinetry when the drying
cabinet is moved to its final location.
1. Place the exhaust collar over the hole in
the drying cabinet’s top plate, align the
screw holes and screw the exhaust collar
into place.
2. Connect the vent pipe if the drying cabinet
is built in, or press the supplied (only cer-
tain markets) flexible hose into place. See
the section ’Ventilation requirements’ on
page 9.
The exhaust collar is designed to be
screwed in place with two screws to
the drying cabinet’s top plate. There are
predrilled holes in the exhaust collar
and top plate.
1. Exhaust collar
Electrical connection
Consult the earlier section ’Electrical requi-
rements’ on page 8.
