ASM Zip-Spray ESP - Specifications

Models
2 311139B
Models
Specifications
This equipment is not intended for use with flammable or combustible materials used in places such as cabinet shops
or other “factory”, or fixed locations. If you intend to use this equipment in this type of application, you must comply
with NFPA 33 and OSHA requirements for the use of flammable and combustible materials.
Model Name,
Model No. Series
Dispense Rate
gpm (lpm)
Hose Length and
Diameter
Gun
Model
Maximum Working
Pressure
PSI MPa bar
ASM ESP
248772
A 0.24 gpm
(0.91 lpm)
25 ft x 1/4 in.
(8 m x 4.8 mm)
200 2800 19 193
ASM 1500
248672
A 0.27 gpm
(1.02 lpm)
25 ft x 1/4 in.
(8 m x 6.3 mm)
200 3000 21 207
ASM 1700
233789
A 0.34 gpm
(2.17 lpm)
50 ft x 1/4 in.
(15.2 m x 6.3 mm)
300 3000 21 207
ASM 1900
248673
A 0.38 gpm
(1.44 lpm)
50 ft x 1/4 in.
(15.2 m x 6.3 mm)
400 3000 21 207
