Component Identification
6 311139B
Component Identification
A
Electric motor (inside enclosures) Provides mechanical power to pump.
B Power switch Manually turns ON and OFF electric power to motor (I is ON
and 0 is OFF.
C Pressure control knob Manually increases (turn clockwise) and decreases (turn
counter-clockwise) fluid pressure in pump, hose, and spray
gun.
D Pump fluid outlet fitting Threaded connection for paint hose.
E Pump fluid filter (1500, 1700 and 1900
models only)
• Filters fluid coming out of pump to reduce tip plugging
and improve finish.
• Self cleans only during pressure relief.
F Durable piston pump (behind Easy
Access door) (1500, 1700, and 1900 mod-
els only)
Pumps and pressurizes fluid and delivers it to paint hose.
Easy Access door permits quick removal of outlet valve.
G Suction tube Draws fluid from paint pail into pump.
H Prime tube (with diffuser) Drains fluid in system during priming and pressure relief.
J Spray- Prime/Drain valve control • In SPRAY position (pointing forward) directs pressurized
fluid to paint hose.
• In PRIME/DRAIN position (pointing down) directs fluid to
drain tube.
• Automatically relieves system pressure in overpressure
situations.
K Fluid inlet connection and inlet valve Suction tube connection to pump and inlet valve.
L Inlet screen Prevents debris from entering pump.
M Paint hose Transports high-pressure fluid from pump to spray gun.
N Cord wrap bracket Stows electrical cord (1500 model only).
P Airless spray gun Dispenses pumped fluid.
Q Tip guard Reduces risk of fluid injection injury.
R Reversible spray tip • Atomizes fluid being sprayed, forms spray pattern and
controls fluid flow according to hole size.
• Reverses for unclogging plugged tips without disassem-
bly.
S Trigger safety lever Prevents accidental triggering of spray gun.
T Gun fluid inlet fitting Threaded connection for paint hose.
U In-handle gun swivel (300 & 400 Series
spray gun only)
Allows spray gun to swivel without twisting paint hose.
V Gun fluid filter (in handle) Filters fluid entering spray gun to reduce tip clogs and
improve finish.
W Hose/cord wrap bracket Stows paint hose and electrical cord (1700 and 1900 models
only).
X Pail hanger For transporting pail by its handle (1700 and 1900 models
only).
Y
Zip-Flush
™
cleaning attachment
(included)
Connects garden hose to suction tube for quick flush of
water-base fluids.
