Technical Data
28 311139B
Technical Data
ASM ESP ASM 1500 ASM 1700 ASM 1900
Working pressure
range
0-2800 psi (0-19 MPa,
0 -193 bar)
0-3000 psi (0-21 MPa,
0-207 bar)
0-3000 psi (0-21 MPa,
0-207 bar)
0-3000 psi (0-21 MPa,
0-207 bar)
Electric motor 6.5 AMP (open frame,
universal)
5.8 AMP (open frame, permanent magnet
DC)
9.4 AMP (open frame,
permanent magnet
DC)
Operating horsepower 3/8 5/8 3/4 7/8
Maximum delivery
(with tip)
0.24 gpm (0.91 lpm) 0.27 gpm (1.02 lpm) 0.31 gpm (1.17 lpm) 0.38 gpm (1.44 lpm)
Paint hose 25 ft (7.6 m) x 1/4 in. 25 ft (7.6 m) x 1/4 in. 50 ft (15.2 m) x 1/4 in. 50 ft (15.2 m) x 1/4 in.
Maximum tip hole size 0.015 in. (0.38 mm) 0.015 in. (0.38 mm) 0.017 in. (0.43 mm) 0.019 in. (0.48 mm)
Weight, sprayer only 15 lb (7 kg) 21 lb (10 kg) 31 lb (14 kg) 35 lb (16 kg)
Weight, sprayer, hose
& gun
18 lb (8 kg) 24 lb (11 kg) 36 lb (17 kg) 40 lb (18 kg)
Dimensions:
Length 17.5 in. (44.5 cm) 13.75 in. (34.9 cm) 19.5 in. (49.5 cm) 19.5 in. (49.5 cm)
Width 18 in. (46 cm) 11 in. (27.9 cm) 17.25 in. (43.8 cm) 19 in. (48.3 cm)
Height 21 in. (53 in.) 19 in. (48.3 cm) 40.75 in. (103.5 cm)*
*Height with folded handle
is 26 in. (66 cm)
40 in. (101.6 cm)*
*Height with folded handle
is 26 in. (66 cm)
Power cord 16 AWG, 3-wire, 6 ft (1.8 m) 16 AWG, 3-wire, 10 ft
(3.05 m)
Fluid inlet fitting 3/4 in. internal thread (standard garden hose thread)
Fluid outlet fitting 1/4 NPSM external thread
Inlet screen on
suction tube
35 mesh (450 micron)
Wetted parts, pump &
hose
stainless steel, brass,
ultra-high molecular
weight polyethylene
(UHMWPE), carbide,
nylon, aluminum,
PVC, polypropylene,
fluroelastomer
stainless steel, brass, leather, ultra-high molecular weight
polyethylene (UHMWPE), carbide, nylon, aluminum, PVC,
polypropylene, fluroelastomer
Wetted parts, gun 200 Series: plated steel, nylon, aluminum,
tungsten carbide, stainless steel, brass,
fluroelastomer
300/400 Series: aluminum, brass, carbide,
nylon, plated steel, stainless steel,
UHMWPE, zinc
Generator
requirement
1500 Watt minimum
Electrical power
requirement
120VAC, 60 Hz, 1 phase, 15A
Storage temperature
range ◆❖
-30° to 160°F (-35° to 71°C)
Operating
temperature range ✔
40° to 115°F (4° to 46°C)
◆ When pump is stored with non-freezing fluid. Pump damage will occur if water or latex paint freezes in
pump.
❖ Damage to plastic parts may result if impact occurs in low temperature conditions.
✔ Changes in paint viscosity at very low or very high temperatures can affect sprayer performance.
