Model W73, Wood Frame
Supplied Fasteners
Closer Screw Pack
(90241)
Closer Track Screw Kit
(90242)
Arm Screw Pack
(70251-nish)
Bottom Pivot Screw Pack
(70243)
Top Pivot Screw Pack
(70242-nish)
Cover Plate Screw Pack
(90278-nish)
5x
1/4-20 x 5/8"
PFHMS
Pivot
5x
#14 x 1-1/2"
PFHWS
Pivot
4x
1/4-20 x 5/8"
PFHMS
Pivot
4x
#14 x 1-1/2"
PFHWS
Pivot
1x
3/8-16 Female
Threaded
Drop-in Anchor
1x
3/8-16 x 2-1/4"
SHCS
Base Plate
2x
8-32 x 1/4"
PFHUCMS
Finish Plate
6x
6-32 x 1/4"
PFHMS
Cover
4x
1/4-20 x 5/8"
PFHMS
Closer Body
2x
10-24 x 3/8"
SHSS
Arm Attach
4x
1/4-20 x 7/16"
PFHUCMS
Track
4x
#14 x 1-1/4"
PFHWS
Track
1x
10-24 x 1-1/2"
SHCS
Arm Clamp
2x
1/4-20 x 1/2"
PFHMS
Arm Attach
4x
#14 x 1-1/2"
PFHWS
Closer Body
5/32"
Hex
Wrench
3/32"
Hex
Wrench
1/8"
Hex
Wrench
3/16"
Hex
Wrench
1x
Conical
Washer
Arm Attach
