4 1-800-810-WIRE • www.sargentlock.com • A8190B
Copyright © 2016, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved.
Reproductions in whole or in part without express written permission of Sargent Manufacturing Company is prohibited.
07/31/16
IN100 Mortise Lock
!
To comply with “Fire Listed” doors, the batteries must be replaced with alkaline batteries only.
General Description
2
The SARGENT
®
IN100 mortise lock with Aperio™ Technology makes it easy and cost-effective to bring
access control to more doors. It uses local wireless communication between the lock and an Aperio hub to
connect to an access control system, eliminating the greatest cost and inconvenience of traditional access
control – the wiring at the door. The IN100 utilizes HID
®
multiCLASS SE
®
technology, it supports heightened
identity security and multiple credentials, including mobile access.
All technology features are supported by the physical security of SARGENT ANSI/BHMA Grade 1 hardware -
quality components that provide high security, performance and durability.
Hardware Specifications
3
• Complete lockset with on-board memory
• ADA compliant
• Easily retrofits existing door preps (mortise)
• Latch - Stainless steel
• Optional deadbolt - Hardened steel
• Guardbolt - Stainless steel, non handed
• Handing (RH/RHR/LH/LHR) must be specified,
but is easily field-reversible without opening
the lock case
• Case - 12 gauge heavy duty wrought steel
• Cylinder retracts latchbolt (and deadbolt)
• Inside lever retracts latch and deadbolt
simultaneously
• Lock furnished for 1-3/4” doors.
For other thicknesses, consult factory.
• UL Listed (3 hr.)
• Outside lever controlled by any combination of
contactless reader or mechanical cylinder
Electronic Specifications
4
*For specific security information, please contact
your local ASSA ABLOY Door Security Solutions
sales consultant or call 800-810-WIRE.
• Input Power: DC 9V, 1.5A (6 AA alkaline batteries)
• Optional hard-power 12VDC to 24VDC
• HID
®
multiCLASS SE
®
technology offers support
for the following credentials:
• High Frequency (13.56 MHz):
• HID iCLASS
®
• HID iCLASS SE
®
(SIO-enabled)
• HID iCLASS
®
Seos
™
• HID MIFARE
®
SE
• HID DESfire
®
EV1 SE
• MIFARE Classic
• DESfire EV1
• Low Frequency (125 kHz):
• HID Prox
®
• NFC-enabled Mobile Phones
Note: A weather-protective gasket is required for exterior applications.
• Uses low-rate wireless personal area networks
(IEEE 802.14.4)
• Multiple time zone and holiday access scheduling
• First-in unlock or automatic unlock configuration,
based on specified time schedule
• Uses AES 128-bit wireless encryption*
• Privacy button
Warning: SARGENT Mfg. Co. IN100 locksets utilizing a door position switch (DPS) are not rated for,
or intended for use in life safety applications.
ITEM PART NUMBER/ORDER STRING DESCRIPTION COLOR/TRIM QTY
1 IN-100-EM01[locktype]*-IP-B HID iCLASS
®
, HID iCLASS SE
®
(SIO-enabled), HID iCLASS
®
Seos™, HID MIFARE
®
SE, HID DESfire
®
EV1 SE, HID Prox
®
Black 1
IN-100-EM01[locktype]*-IP-W HID iCLASS
®
, HID iCLASS SE
®
(SIO-enabled), HID iCLASS
®
Seos™, HID MIFARE
®
SE, HID DESfire
®
EV1 SE, HID Prox
®
White 1
IN-100-EM01[locktype]*-IP-MB-[xxx]* HID iCLASS
®
, HID iCLASS SE
®
(SIO-enabled), HID iCLASS
®
Seos™, HID MIFARE
®
SE, HID DESfire
®
EV1 SE, HID Prox
®
Black with metal trim 1
IN-100-EM01[locktype]*-IP-MW-[xxx]* HID iCLASS
®
, HID iCLASS SE
®
(SIO-enabled), HID iCLASS
®
Seos™, HID MIFARE
®
SE, HID DESfire
®
EV1 SE, HID Prox
®
White with metal trim 1
IN-100-EM01[locktype]*-IPS-B All credentials supported by IP option plus MIFARE Classic and DESfire EV1 Black 1
IN-100-EM01[locktype]*-IPS-W All credentials supported by IP option plus MIFARE Classic and DESfire EV1 White 1
IN-100-EM01[locktype]*-IPS-MB-[xxx]* All credentials supported by IP option plus MIFARE Classic and DESfire EV1 Black with metal trim 1
IN-100-EM01[locktype]*-IPS-MW-[xxx]* All credentials supported by IP option plus MIFARE Classic and DESfire EV1 White with metal trim 1
2 IN-EM04 Mounting plate assembly 1
3 N/A AA battery 6
4 IN-100-EM02-B Inside Escutcheon Assembly with Privacy Button - Black Plastic Black 1
IN-100-EM02-W Inside Escutcheon Assembly with Privacy Button - White Plastic White
IN-100-EM02-MB-xxx** Inside Escutcheon Assembly with Privacy Button - Black Plastic & Metal Trim Black with metal trim
IN-100-EM02-MW-xxx** Inside Escutcheon Assembly with Privacy Button - White Plastic & Metal Trim White with metal trim
