1. INTRODUCTION
This User Guide has been prepared to assist with the installation of a Traka Touch S System and additional extensions.
2. PRODUCT DETAILS
2.1 ELECTRICAL RATING
Power supply: Input: 100-240V AC, Output: 15V DC
Battery backup: DC12v 4.2Ah
Power consumption: 35W max
2.2 ENVIRONMENTAL RATING
Operating temp: Ambient, for indoor use only (-5°C to +40°C at 95% non-condensing relative humidity)
2.3 COMPLIANCE LEVEL
2.3.1 USA AND CANADA
CAN/ULC S319
ULC S319 Class = Class 1
The product’s or component’s compliance to ULC-S319 would be invalidated through the use of any add-on, expansion,
memory, or other module manufactured or supplied by the manufacturer or manufacturer’s representative.
UL294
The levels of access/class of protection are summarised below:
• Attack Level – Level IV
• Endurance Level – Level IV
• Line Security Level – Level I
• Standby Power Level – Level IV
2.3.2 EUROPE
Contact Traka for a copy of the CE declaration of conformity.
