3.INSTALLATION AND CONNECTION
NOTICE TO INSTALLERS
Heat Pump must be located outdoors with sufficient ventilation as explained on page 9.
This appliance must be installed by an authorized person.
This appliance must be installed in accordance with the installation instructions, the National Wiring Rules and any othe
r
relevant
statutory authorities.
Refer to data plate for details of operating voltage and current.
A multi-pole isolating switch must be installed that operates in all live conductors so that it isolates the entire equipment from the
supply.
SAFETY RULES
1.
2.
3.
4.
5.
6.
Spa or hot tub water temperature should never exceed40˚C.
Drinking of alcoholic beverages before or during spa or hot tub use can cause drowsiness which could lead to
unconsciousness and subsequently result in drowning.
Pregnant women beware! Soaking in water above 38˚C can cause foetal damage during the first three months of
pregnancy.
Before entering the spa or hot tub, the user should check the water temperature with an accurate thermometer, spa or hot
tub thermostats may be inaccurate by as much as 2˚C.
Persons with a medical history of heart disease, circulatory problems, diabetes or blood pressure problems should obtain
their physician’s advice before using spas or hot tubs.
Persons taking medications which induce drowsiness, such as tranquillisers, antihistamines or anticoagulants, should not
use spas or hot tubs. If in doubt seek medical advice.
Phase rotation must be checked on 3 phase units. Incorrect rotation will damage the compresso
r
and void any warranties.
Performance data of Swimming Pool Heat Pump Unit
CHEMICAL BALANCE
It is imperative that correct chemical balance be maintained in your pool and spa water, otherwise corrosion of you
r
heater ma
y
occur. Corrosion due to chemically imbalanced water or excessive sanitise
r
is detectable and will void warranty. Your
local pool shop specialist or spa retailer can advise correct chemical balance. Your water should be checked and maintained
regularly by a pool water professional. As a guide the following parameters may be used.
pH
Total Alkalinity
Calcium Hardness
7.6 to 7.8
80 to 120 ppm
150 ppm
You should test your water chemical balance at least on a weekly basis.
Excessive sanitise
r
can damage your heater. Chlorine should not exceed 3 ppm and bromine should not exceed 5 ppm. Salt
chlorinators, especially when used on spa pools or indoor or covered pools, can easily produce excessive chlorine levels which will
damage the heater internals.
WINTER OPERATION
If the pool won’t be used for a month o
r
more, turn the heater off at the main isolating switch. For areas where there is no danger of
freezing, water should circulate through your heater all year long even though you are not heating your pool.
Where freezing is possible, it is necessary to drain the water from the heater. This may be done by loosening the inlet or outlet
barrel union. If the heater is below water level, isolate it from the pool first by closing shut off valves before and after the heater.
CAUTION: If the heater has been drained for freezing conditions, do not turn on until the system is circulating water.
2
