H87-PLUS specications summary
CPU LGA1150 socket for Intel
®
4th Generation Core™ i7 / Core™ i5 /
Core™ i3, Pentium
®
, and Celeron
®
processors
Supports 22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU
types.
** Refer to
www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H87 Express Chipset
Memory 4 x DIMM, max. 32GB, DDR3 1600 / 1333 / 1066 MHz, non-ECC,
un-buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of
individual CPUs. Please refer to Memory QVL (Qualied Vendors List)
for details.
** Refer to
www.asus.com for the Memory QVL (Qualied Vendors List).
*** Due to Intel
®
chipset limitation, DDR3 1600 MHz and higher memory
modules on XMP mode will run at the maximum transfer rate of DDR3
1600 Mhz.
Expansion slots 1 x PCI Express 3.0/2.0 x16 slots [yellow] (at x16 mode)
1 x PCI Express 2.0 x16 slot [dark brown] (run at x4 mode,
compatible with PCIe x1 and x4 devices)
2 x PCI Express 2.0 x1 slots
3 x PCI slots
VGA
Integrated Graphics Processor - Intel
®
HD Graphics support
Multi-VGA output support: HDMI/DVI-D/RGB port
Supports HDMI with max. resolution of 4096 x 2160 @24Hz / 2560
x 1600 @60Hz
Supports DVI-D with max. resolution of 1920 x 1200 @60Hz
Supports RGB with max. resolution of 1920 x 1200 @60Hz
Maximum shared memory 1024MB
Supports up to three displays simultaneously
Multi-GPU support Supports AMD
®
Quad-GPU CrossFireX™ Technology
Storage
Intel
®
H87 Express Chipset
- 6 x SATA 6.0 Gb/s ports (yellow) with RAID 0, 1, 5, 10 support
- Supports Intel
®
Smart Response Technology, Intel
®
Rapid Start
Technology, and Intel
®
Smart Connect Technology*
* These functions will work depending on the CPU installed.
LAN Realtek
®
8111G Gigabit LAN controller
(continued on the next page)
