IPIBL-LA(Berkeley-GL8E)18
8. Internal audio connector (F_LINE_IN [White])
Thisconnectorallowsyoutoreceivestereoaudioinputfromsoundsources
suchasaCD-ROM,TVtuner,orMPEGcard.
7. CPU and System fan connectors (4-pin CPU_FAN1, 3-pin SYS_FAN1)
Thesefanconnectorssupportcoolingfansof350mA~740mA(8.88Wmax.)
oratotalof1A~2.22A(26.64Wmax.)at+12V.Connectthefancablesto
thefanconnectorsonthemotherboard,makingsurethattheblackwireof
eachcablematchesthegroundpinoftheconnector.
Donotforgettoconnectthefancablestothefanconnectors.Insufcientair
owinsidethesystemmaydamagethemotherboardcomponents.Theseare
notjumpers!DOnotplacejumpercapsonthefanconnectors.
IPIBL-LA
IPIBL-LA(Berkeley-GL8E)
Fan connectors
CPU_FAN1
SYS_FAN1
GND
Rotation
+12V
PWN
GND
Rotation
+12V
IPIBL-LA
IPIBL-LA(Berkeley-GL8E)
Internal audio connector
P2
AUX_LCR
AUX_RCR
GND
SENSE
