Asus IPIBL-LA Berkeley-GL8E - Digital;Front Panel Audio Connector

IPIBL-LA(Berkeley-GL8E) 19
10. Front panel audio connector (10-1-pin F_AUDIO)
Thisconnectorisforachassis-mountedfrontpanelheadphoneport.
9. Digital audio connector (3-pin SPDIF2 [White])
ThisconnectorisforanadditionalSony/PhilipsDigitalInterface(S/PDIF)
port(s).ConnecttheS/PDIFmodulecabletothisconnector,theninstallthe
moduletoaslotopeningatthebackofthesystemchassis.
TheS/PDIFmoduleispurchasedseparately.
IPIBL-LA
IPIBL-LA(Berkeley-GL8E)
Digital audio connector
SPDIF2
SPDIFOUT
GND
+5V
IPIBL-LA
GND AUDIO_PRES# MIC2_RTU LIN2_RTU
MIC2_L
MIC2_R
LIN2_R
SENSE
LIN2_L
IPIBL-LA(Berkeley-GL8E)
Front panel audio connector
P1
PIN1
