Asus P5SD2-VM User Manual

ASUS P5SD2-VM 1-7
1.5.3 Motherboard layout
Refer to section 1.10 Connectors for more information about rear panel
connectors and internal connectors.
SIS 672
SIS 968
1
8.3cm
(
7.2in
)
18.8cm(7.4in)
24.4cm(9.6in)
DDR2 DIMM1 (64 bit,240-pin module)
DDR2 DIMM
2
(64 bit,240-pin module)
PCIEX16
PCI1
PCI2
PCIEX1_1
CD
ALC662
AAFP
USB56
USB78
SATA2
SATA1
CR2032 3V
Lithium Cell
CMOS Power
CLRTC
SPEAKER
SPDIF_OUT
CHASSIS
F_PANEL
Super I/O
SB_PWR
FLOPPY
EATXPWR
CPU_FAN
ATX12V
PRI_IDE
PS/2KBMS
T: Mouse
B: Keyboard
LAN1_USB12
COM1
PARALLEL PORT
VGA1
USB34
LGA775
P5SD2-VM
Atheros
F2
RTM876-660
PS2_USB_PWR
CHA_FAN
AUDIO
4Mb
BIOS

Asus P5SD2-VM Specifications

General

Form Factor	Micro ATX
Socket	LGA 775
Front Side Bus	1066/800/533 MHz
Memory Type	DDR2
Memory Slots	2 x DIMM
Maximum Memory	2 GB
LAN	Realtek RTL8201CL 10/100 Mbps Ethernet
USB Ports	8 x USB 2.0
Supported CPU	Intel Pentium 4
Expansion Slots	1 x PCIe x16
Audio	6-channel HD Audio
Integrated Graphics	SiS Mirage 1
