Asus P5SD2-VM User Manual

ASUS P5SD2-VM 2-23
South Bridge Conguration
OnBoard Audio DEVICE [Enabled]
Front Panel Support Type [HD Audio]
OnBoard SiS191 Lan Device [Enable]
OnBoard LAN Boot ROM [Disabled]
A11 PCI EXPRESS Controller [Enabled]
A11 PCI EXPRESS INTPIN [Disabled]
Onboard Audio Device [Enabled]
This item enables or disables the onboard audio device.
Conguration options: [Disabled] [Enabled]
Front Panel Support Type [HD Audio]
Allows you to select the front panel support type.
Conguration options: [AC97] [HD Audio]
OnBoard SiS191 Lan Device [Enabled]
Allows you to enable or disable the onboard LAN controller.
Conguration options: [Disabled] [Enabled]
OnBoard LAN Boot ROM [Enabled]
Allows you to enable or disable the option ROM in the onboard LAN controller.
This item appears only when the Onboard LAN item is set to Enabled.
Conguration options: [Disabled] [Enabled]
A11 PCI EXPRESS Controller [Enabled]
Allows you to enable or disable the A11 PCI Express Controller.
Conguration options: [Disabled] [Enabled]
A11 PCI EXPRESS INTPIN [Disabled]
Allows you to enable or disable the A11 PCI Express INTPIN.
Conguration options: [Disabled] [Enabled]
Enable/Disable
onboard Audio device

Asus P5SD2-VM Specifications

General

Form Factor	Micro ATX
Socket	LGA 775
Front Side Bus	1066/800/533 MHz
Memory Type	DDR2
Memory Slots	2 x DIMM
Maximum Memory	2 GB
LAN	Realtek RTL8201CL 10/100 Mbps Ethernet
USB Ports	8 x USB 2.0
Supported CPU	Intel Pentium 4
Expansion Slots	1 x PCIe x16
Audio	6-channel HD Audio
Integrated Graphics	SiS Mirage 1
