ASUS P5SD2-VM 2-27
2.5.5 APM Conguration
APM Conguration
Power On By Ring [Disabled]
Power On By LAN [Disabled]
Power On By PME# [Disabled]
Power On By RTC [Disabled]
Restore on AC Power Loss [Power Off]
Power On By PS/2 Keyboard [Disabled]
Power On By PS/2 Mouse [Disabled]
Power On By Ring [Disabled]
Allows you to enable or disable RI to generate a wake event.
Conguration options: [Disabled] [Enabled]
Power On By LAN [Disabled]
Allows you to enable or disable LAN GPI to generate a wake event.
Conguration options: [Disabled] [Enabled]
Power On By PME# [Disabled]
Allows you to enable or disable PME to generate a wake event.
Conguration options: [Disabled] [Enabled]
Power On By RTC [Disabled]
Allows you to enable or disable RTC to generate a wake event. When this item is
set to Enabled, the items RTC Alarm Date, RTC Alarm Hour, RTC Alarm Minute,
and RTC Alarm Second appear with set values.
Conguration options: [Disabled] [Enabled]
Restore on AC Power Loss [Power Off]
When set to Power Off, the system goes into off state after an AC power loss.
When set to Power On, the system goes on after an AC power loss. When set to
Last State, the system goes into either off or on state, whatever the system state
was before the AC power loss.
Conguration options: [Power Off] [Power On] [Last State]
Power On By PS/2 Keyboard [Disabled]
Allows you to use specic keys on the keyboard to turn on the system. This
feature requires an ATX power supply that provides at least 1A on the +5VSB lead.
Conguration options: [Disabled] [Space Bar] [Ctrl-Esc] [Power Key] [Any Key]
Disable/enable RI
to generate a wake
event.

Asus P5SD2-VM Specifications

General

Form Factor	Micro ATX
Socket	LGA 775
Front Side Bus	1066/800/533 MHz
Memory Type	DDR2
Memory Slots	2 x DIMM
Maximum Memory	2 GB
LAN	Realtek RTL8201CL 10/100 Mbps Ethernet
USB Ports	8 x USB 2.0
Supported CPU	Intel Pentium 4
Expansion Slots	1 x PCIe x16
Audio	6-channel HD Audio
Integrated Graphics	SiS Mirage 1
