Asus ROG Strix G13CH - CPU Fan 12 CM Removal; Step 1: Disconnect CPU Fan; Step 2: Remove CPU Fan Screws; Step 3: Remove CPU Fan

CPU FAN 12CM
Step 1 : Disconnect (yellow mark) FAN connector *1pc.
Step 2 : Remove screws *4pcs on the outside of iron grid.
Step 3 : Take out the Fan*1 pcs.
Disconnect (yellow mark)
Back
20
Disassembly Notice
Please be sure to pull out AC POWER CORD.
3
1
2
Remove
Screws QTY Spec
Torque (
kgf-
cm)
4 M5*10L (K) B-NI TAPPING
8.0±0.5
Assembly Notice
Please follow the below criteria to assemble FAN.
CPU FAN 12CM
