Asus ROG Xonar Phoebus - Connecting 5.1 channel headphones

15
ASUS Xonar Phoebus
No Item Description
1 Front Out
Connect the front-channel 3.5mm plug of your 5.1
headphones into this jack.
2 Back Surround Out
Connects to the Back Surround input port with the mini-
jack cable.
3 Center/Subwoofer
Out
Connect the Center/Bass-channel 3.5mm plug of your
5.1 headphone into this jack.
Connecting 5.1 channel hadphones
Mic in
HP out
Box link
Line in
Front
Ctr / Sbw
Rear
Side /
SPDIF out
1
2
3
