Asus RS500-E8-PS4 - Single Cpu Configuration

2-11
ASUS RS500-E8 Series
Dual CPU configuration
DIMM (CPU1) DIMM (CPU2)
A2 A1 B2 B1 C2 C1 D2 D1
E2 E1 F2 F1 G2 G1 H2 H1
2 DIMMs
P P
4 DIMMs
P P P P
8 DIMMs
P P P P P P P P
12 DIMMs
P P P P P P P P P P P P
16 DIMMs
P P P P P P P P P P P P P P P P
Single CPU configuration (must be installed on CPU1)
DIMM
A2 A1 B2 B1 C2 C1 D2 D1
1 DIMM
P
1 DIMM
P
2 DIMMs
P P
4 DIMMs
P P P P
8 DIMMs
P P P P P P P P
Dual CPU configuration
You can refer to the following recommended memory population for a dual CPU conguration.
Single CPU configuration
You can refer to the following recommended memory population for a single CPU conguration.
