Chapter 4: BIOS setup
4.7 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you to change
the fan settings.
CPU/MB/TR1 Temperature [xxx°C/xxx°F]
The onboard hardware monitor automatically detects and displays the CPU and motherboard
component temperatures.
CPU_FAN1 Speed; FRNT_FAN1–3 Speed; REAR_FAN1 Speed [xxxx RPM] or
[Ignore] / [N/A]
The onboard hardware monitor automatically detects and displays the speed of CPU fans,
front fans, and rear fan in rotations per minute (RPM). If the fan is not connected to the
motherboard,theeldshowsN/A.
VCORE1 Voltage: +12V, +5V, +VDDQ, +3VSB, +3.3V, and VBAT
The onboard hardware monitor automatically detects the voltage output through the onboard
voltage regulators.
Fan Speed Control [Generic Mode]
AllowsyoutoconguretheASUSSmartFanfeaturethatsmartlyadjuststhefanspeedsfor
moreefcientsystemoperation.Congurationoptions:
[LowSpeedMode][GenericMode][HighSpeedMode][FullSpeedMode]
Whisper/Generic/High/Speed/
Full Speed
Aptio Setup Utility - Copyright (C) 2014 American Megatrends, Inc.
Main Advanced Event Logs Boot Monitor Security Tool Exit
Monitor
CPU Temperature : +58ºC/ +162ºF
MB Temperature : +52ºC/ +151ºF
TR1 Temperature : N/A
CPU_FAN1 Speed : 1054 RPM
REAR_FAN1 Speed : N/A
FRNT_FAN1 Speed : N/A
FRNT_FAN2 Speed : N/A
FRNT_FAN3 Speed : N/A
VCORE1 : +1.800 V
+12V : +12.288 V
+5 : +5.040 V
+VDDQ : +1.504 V
+3VSB : +3.408 V
+3.3V : +1.296 V
VBAT : +3.344 V
FAN Speed Control [Generic Mode]
