31/46
Figure 6-7: HMI simulation case 3 – ‘Centring'
6.4.4. Case 4: Mixed smart vibrations
Most situations require the combination of both smart vibrations: a feeding vibration
(hopper vibration/output activation) in ‘Quantity adjusted’ duration mode combined
with ‘Centring'. In this mixed case, the simulation interface is the combination of the
ones presented previously (Figure 6-6 and Figure 6-7).
