2.2. General procedure overview
The table below presents the general procedure to set up your Asycube for your specific
application. The next chapters of this document follow the order of the general procedure and
at the end of this document, a step-by-step example summarises the different aspects
approached.
Steps
1. Install and configure the Asyril HMI
3. Asyril HMI installation
page 11
2. Adjust platform and hopper vibrations/output
activations
a. for part family 1 (vibration set 1)
b. for part family 2 (vibration set 2)
c. for part family 3 (vibration set 3)
d. etc.
4. Hopper
vibration/output
activation
5. Platform vibration
9. Example
page 13
page 16
page 36
3. Adjusting sequences
a. for scenario 1, smooth platform, (Sequence 1)
b. for scenario 2, structured platform, (Sequence 2)
c. for scenario 3, smooth platform, (Sequence 3)
d. etc.
6. Sequence
9. Example
page 24
page 36
4. Save all the parameters in the Asycube
7. Saving
page 32
5. Configure the backlight
8. Backlight
page 34
6. Control the Asycube from a PLC
(Programmable Logic Controller)
a. Select a vibration set
b. Execute a sequence
c. Activate the backlight
d. etc.
9. Example
page 36
Table 2-2: General procedure overview
