AdvanTag 9100 Technical Manual
Chapter 2: Theory of Operation
Data Storage—AdvanTag Reader
a
PIP Pod In Place status
PIP_AUTOREAD_DATA The memory type to read upon Pod-In-Place
Event:
(Offset, or MID)
Note: Offset applies only to NOTEPAD.
Note: This attribute should be modified with
respect to PIP_AUTOREAD_LENGTH
Default = MID
PIP_AUTOREAD_LENGTH Length of NOTEPAD data to read upon Pod
arrival.
Note: Applicable only if data type is
NOTEPAD
Note: This attribute should be modified with
respect to PIP_AUTOREAD_DATA
Default = 16
PIP_SENSOR_POLARITY PIP Sensor Polarity.
HI = Active-High. When Sensor goes high,
Pod Arrival event is generated
LO = Active-Low. When Sensor goes low, Pod
Arrival event is generated
Default = LO
RDA
(Applicable only to version 21A
and later)
AdvanTag returns either RD or RDA in
response to the ASCII RD command.
EN = Enabled, returns RDA
DI = Disabled, returns RD
Default = EN
SECS_T1 (SECS only) SECS T1 timeout
Default = 5
SECS_T2 (SECS only)
(Host port on LM)
SECS T2 timeout
Default = 50
SECS_T3 (SECS only)
(Host port on LM)
SECS T3 timeout
Default = 45
SECS_T4 (SECS only)
(Host port on LM)
SECS T4 timeout
Default = 45
SECS_RETRY (SECS only)
(Host port on LM)
SECS-1 Protocol Retry limit
Default = 3
SERIALNUM The SerialNumber
SerialNumber
(Applicable only to version 21A
and later)
Same as SerialNumber
TABLE 3 Attribute Values (ECID and SVID)
Attribute Description and Limits or Values
