Rev. AX5 Draft Page 19
AdvanTag 9100 Technical Manual
Chapter 2: Theory of Operation
Data Storage—AdvanTag Reader
a
Manufacturer
(Applicable only to version 21A
and later)
Returns “Asyst”
MANTWRITEONLY If this attribute is enabled, then MID (CID)
and Data is read and written according to the
E99 standard
EN = Enable
DI = Disable
Default = DI
MDLN Asyst Model designation of Upstream
Controller OR Head (as applicable)
Up to 8 bytes
ModelNumber
(Applicable only to version 21A
and later)
Same as MDLN
OIP Operator Arrival Status
OIP_AUTOREAD Auto read On or OFF
ON = On
OFF = Off
Default = OFF
OIP_AUTOREAD_DATA The memory type to read upon Pod-In-Place
Event:
(Offset, or MID
Note: Offset applies only to NOTEPAD.
This attribute should be modified with respect
to OIP_AUTOREAD_LENGTH
Default = MID
OIP_AUTOREAD_LENGTH Length of NOTPAD data to read upon
Operator arrival.
Applies only to NOTEPAD
Note: This attribute should be modified with
respect to OIP_AUTOREAD_DATA
Default = 16
OIP_SENSOR_POLARITY OIP Sensor Polarity.
HI = Active-High. When Sensor goes high,
Operator Arrival event is generated
LO = Active-Low. When Sensor goes low,
Operator Arrival event is generated
Default = LO
OperationalStatus
(Applicable only to version 21A
and later)
IDLE or MANT
Note: Set through only Subsystem commands
TABLE 3 Attribute Values (ECID and SVID)
Attribute Description and Limits or Values
