11.4 Display messages
The machine, during operation, displays messages regarding its status or any malfunctions.
Here is an example of how a message is shown on the display (see paragraph 11.2.1 “Display”):
The following table indicates, in the "Phase" column, the messages that appear on the display (some messages are displayed in a
single line on the display). The "Description" column gives a simple explanation of the message:
Phase Description
A
AT-OS
Rev. 0-0
The message appears when the machine is started and furnished with electrical energy. It indicates the
program version installed in the machine.
B1
Set-up
Please wait
The message appears after switching on the machine, while executing setting of the general system.
B2
MP0227AA Rev. x.x
MP0225AA Rev. x.x
The message advises informations regarding the software versions installed in the unit.
C
Program selection
The message appears when the machine is in stand-by, waiting for the user to select the program: the
machine is operational.
D
Program xx
Cold Rinsing zz°C
The message appears during the wash cycle (the number "xx" indicates the cycle that is selected) when
the machine is performing a cold water wash.
E
Program xx
Hot rinsing zz°C
The message appears during the wash cycle (the number "xx" indicates the cycle that is selected) when
the machine is performing a hot water wash.
F
Program xx
Mix rinsing zz°C
The message appears during the wash cycle (the number "xx" indicates the cycle that is selected) when
the machine is performing a hot and cold water wash.
G
Program xx
Cool down zz°C
The message appears when the interior of the wash basin is cooling down or when the temperature of
the water in the internal boiler is cooling down. This takes place at the end of a wash cycle or whenever
a wash cycle has been interrupted.
H
Program xx
Disinfection zz°C
The message appears during the wash cycle when the cycle is disinfecting the items contained in the
machine.
I*
Cycle End
Take Objects Out
The message gives notice that the wash cycle is terminated and that the door can be opened to remove
the cleaned and disinfected items.
L
Refill Softener This message warns the user that the anti-scale product in the drum is getting low. It permits the user to
prepare a replacement drum to use when the liquid is finished (a message in this regard will appear on
the display).
M
Refill Detergent This message warns the user that the detergent (when provided) in the drum is getting low. It permits
the user to prepare a replacement drum to use when the liquid is finished (a message in this regard will
appear on the display).
N
Refill Solvent This message warns the user that the solvent (when provided) in the drum is getting low. It permits the
user to prepare a replacement drum to use when the liquid is finished (a message in this regard will
appear on the display).
O
Interface Error This warns the operator that there has been a wrong procedure when using the machine or that there are
data transmission problems between the electronic cards.
P
Close the door
This is displayed when a wash program has been selected but the door, being open, prevents the
machine from starting. It asks the user to close the door.
Q
Call Service This is displayed when a Technician must be called to solve a frequent problem or machine malfunction.
R**
Maintenance This warns the user that it is time to perform scheduled periodic maintenance (contact the AT-OS S.r.l.
Customer Service Department or authorized technicians).
* : If the machine is equipped with an automatic door with self-opening at the end of the cycle, this message is not displayed.
** : For this type of message, see paragraph 12.3 “Scheduled Maintenance” on page50.
P r o g r a m 3
D i s i n f e c t i o n 8 5 ° C
