(2) Creating Data Table
(2-1) Definition and Format of Data Table
① The data table consist of the following three definitions: temperature, Refractive Index, and
Concentration.
② The maximum number of data points possible is: 6 for temperature and 7 for Concentration.
③ The temperature is displayed by 3 digits and 1 decimal place (000.0).
The Concentration is expressed by a 6-digit number.
A decimal point can be placed anywhere within the 6 digits.
The Refractive Index (nD) is expressed by a 5-digit number.
In case of a 4-digit number, add a "0 (zero)" at the end to make it 5 digits long.
④ Create a table based on the information above.
Table 11-4
※ C1～C7 : Concentration or dilution coefficient, etc.
Enter up to 7 points. Fill in any blank cells with "0.0".
Input condition : C1＜C2＜C3＜C4＜C5＜C6＜C7
C1＞C2＞C3＞C4＞C5＞C6＞C7
※ T1~T6 : Measurement temperature
Enter up to 6 points. Fill in blank cells, if any, with "0.0".
Input condition : T1＜T2＜T3＜T4＜T5＜T6
※ nD10~nD66 : Refractive Index (nD) by Concentration and by temperature
Input condition : nD10＜nD11＜nD12＜nD13＜nD14＜nD15＜nD16
nD20＜nD21＜nD22＜nD23＜nD24＜nD25＜nD26
nD30＜nD31＜nD32＜nD33＜nD34＜nD35＜nD36
nD40＜nD41＜nD42＜nD43＜nD44＜nD45＜nD46
nD50＜nD51＜nD52＜nD53＜nD54＜nD55＜nD56
nD60＜nD61＜nD62＜nD63＜nD64＜nD65＜nD66
※ Fill in any blank cells with "0.0."
※ If the measured value is outside the range in this table, "LLLLLL" or "HHHHHH" is displayed.
※ If the measured temperature is outside the range in this table, "d. Err" is displayed.
To Next Page
