54
17. Dimensions
Detection section (Weight：4.1kg)
Display section (Weight : 3.3kg)
※ Dimensions are approximate.
192
240
100
2.3
10
2-φ6.5
224
180
156.6
224
183.6
208
(50)
(22.5)
182
+1
0
210
+1
0
(31.8)
Prism base: Sapphire
Prism head: SUS316L
External pipe: SUS316L
Cooling fin
AL
Lid for cooling fin
AL
Temperature sensor
