Atari 130XE Service Manual

KEYBOARD REMOVAL/REPLACEMENT
1. Remove the top cover from the console.
2. Remove the keyboard connector and LED connector. Note the position of the LED
connector for reference during assembly.
3. Remove the four screws which hold the keyboard to the top cover. 4. Remove the
keyboard from the top cover.
TO REPLACE THE KEYBOARD
1. Place the top cover upside down on the workbench.
2. Install and position the new keyboard.
3. Insert and tighten the four screws which hold the keyboard to the top cover.
4. Attach the keyboard connector and the LED connector (Be careful not to twist the
LED connector cable).
COLOR ADJUSTMENT
Adjustment can be made through bottom cover.
130XE Personal Computer
Field Service Manual 4-3
