QSG_D6 CLASS_439.00_EN_01 /_2020-05-04
11/38
Ref
Name
Description
1
J1
Analog outputs - pressure and flow (option)
2
J5
Fieldbus connector
3
J8*
Extender (not operational)
4
J10
Program selection extension connector (option)
5
J12
Printer RS232 connector / Modbus (option) or Profibus
(option)
6
M1
External capillary option
7
J13
Temperature probe connector (option for external capillary)
8
P
External back pressure connector (option)
9
-
Input connector to the air filter (valves or regulator air
supply)
10
-
0.6 MPa valves air supply input (1 MPa range) or vacuum
input
11
TEST
Capillary connector to connect to the part under test
12
-
Regulator output (indirect mode or bypass option or
external capillary option)
13
-
Pneumatic output for external bypass option
14
ATM
Output capillary (indirect mode): has to be left to the
atmosphere
15
B
Pneumatic output for external shut off option or B
automatic connector option
16
ATM
Output to be left to the atmosphere
17
A
Pneumatic output for external dump option or A automatic
connector option
18
ATM
Output to be left to the atmosphere
19
-
Air supply energy information
20
ATEQ
Part number / Serial number
21
M2
External capillary connector (option)
22
-
Ground
23
J11
Relay board connector (digital inputs/outputs and 24 V DC
- 2 A
power supply)
24
J9
Outputs code board connector (digital inputs/outputs)
25
J7
Connector for 24 V DC - 2 A or 100 / 240 V AC power
supply
(according option provided)
26
J4*
USB (not operational)
27
J3*
Dry contact input for ERD test mode (option)
28
J6
Fieldbus connector
29
J2*
Network (not operational)
* These connectors are not operational. They are provided for future development
of our devices.
