ATEQ D6 Series Quick Start Guide

QSG_D6 CLASS_439.00_EN_01 /_2020-05-04
30/38
Starting up
POWER UP
1. Make sure that all the necessary connections
are in place.
Electrical: such as power supply, inputs/outputs
Pneumatic: including line pressure supply.
2. Power up your device
When power-up is completed, the Program screen
is displayed, with last program used on screen.
PREPARING A PROGRAM
Use this procedure to configure a new test program.
On the MAIN MENU screen:
ACCESSING THE PARAMETERS
1. Select PARAMETERS using the up/down
keys and then press .
The program list is displayed.
SELECTING A PROGRAM NUMBER
2. Select the program to configure and press .
A list of the available measurement types is displayed:
— DIRECT FLOW type
— INDIRECT type
— OPERATOR type
— QUICK TEST type.
