ATEQ D6 Series Quick Start Guide

QSG_D6 CLASS_439.00_EN_01 /_2020-05-04
38/38
Specifications
CHARACTERISTICS
Technical characteristics of the device.
Main characteristics:
Characteristics
Values
Case dimensions: Height x Width x Depth
150 x 250 x 270 mm
Overall dimensions
150 x 250 x 360 mm
Format
Half 19-inch rack
Mass
About 8 kg (17.6 lbs)
Electrical power supply
— 100 / 240 V AC - 50 W - 50/60 Hz
— 24 V DC - 2 A.
Overvoltage category
II
Pneumatic air supply (0 to 0.5 MPa range)
Air supply: 0.6 MPa ± 15%
Pneumatic air supply (0.6 to 1 MPa range)
— Regulator input: 1.2 MPa ± 10%
— Valves supply: 0.6 MPa ± 15%
Pneumatic air supply (1.1 to 2 MPa range)
— Regulator input: instrument pressure range
+ 0.1 to 0.2 MPa
— Valves supply: 0.6 MPa ± 15%
Protection
Device protection level IP2
Pneumatic connections: (inside / outside
diameters)
4/6 to 26 mm
Operation temperature
+5 °C to + 45 °C (+ 41 °F to 113 °F)
Storage temperature
0 °C to +60 °C (32 °F to 140 °F)
Operation altitude
Up to 2000 m (6500 ft)
Relative humidity
80 % at 31 °C (87 °F) and 50 % at 40 °C (104 °F)

ATEQ D6 Series Specifications

General

Brand	ATEQ
Model	D6 Series
Category	Test Equipment
Language	English
