Chapter 3 – Starting up and adjustments
UM-30200D-U User manual H6000 Page 20 / 58
2. MEASUREMENT RUNNING
The measurement is prompted by pressing the
key on the front face.
Prog n°1 ml/s
PressX to measure
S
T
: Program +/-
The device is waiting for leak detection…
Prog n°1 ml/s
During the measurement the device displays the
numeric value and the bar graph.
Prog n°1 ml/s
7.2 E-5
™™™™™™™
In fixed version, at the end of the test time, the
device is displaying the higher value detected and
the result:
PASS, RECOVERABLE or FAIL.
Prog n°1 ml/s
7.2 E-5
PASS
2.1. REJECT LEVEL
To adjust the reject level from a calibrated leak, see paragraph 3 "Reject level
adjustment cycle" in this chapter.
2.2. BAR GRAPH
The "Bar graph" displays the proportion of the
measurement between zero and the set reject
value.
Prog n°1 ml/s
7.2 E-5
™™™™™™™™™™™
2.3. S
OUND AND VIBRATE ALERTS
During the measurement, to help the leak detection, the sniffer makes a sound with a
frequency higher or lower according with the leak value:
9 Low frequency: small leak.
9 High frequency: large leak or near the reject level.
If the reject level is over passed, the vibrator runs during one second.
