ATESS PBD250 - Factory Settings; LCD Display Information Schedule; Troubleshooting Methods and Steps

The value on this page are important factory preset parameters. Please do not modify them without the consent of ATESS.
The page without instructions is the factory preset parameter, please do not modif.
If the subsequent scheme changes, please modify the parameters under the guidance of ATESS.
3. Factory settings
Clicking “historical information” can enter into the sub-menu of the "historical information".
The submenu includes: Common historical failure, serious historical failure. Via the left button you can
enter the corresponding submenu interface. The "common historical faults"is the default interface.
7. 2.5 Historical information
History of failure: all the common history of failure details can be found by flipping the page up and down.
and you can empty the table by deleting it.
Regarding more info for the common fault information, see table 7.3.
7.3 LCD display information schedule
General history failure table
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
PV_Inverse_Failure
IGBT_Failure
EEPROM_Write_Failure
EEPROM_Read_Failure
MainContactor_Failure
SlaveContactor_Failure
RISO_Failure
PV1_VoltHigh_Fault
PV2_VoltHigh_Fault
PV1_CurrHigh_Fault
PV2_CurrHigh_Fault
BAT_OverVolt_Fault
BAT_UnderVolt_Fault
BAT_OverCurr_Fault
BAT_OverCharge_Fault
OUT_OverVolt_Fault
OUT_OverCurr_Fault
PV_L1_BuckOverCurr_Fault
PV_L2_BuckOverCurr_Fault
OUT_L1_BuckOverCurr_Fault
OUT_L2_BuckOverCurr_Fault
BMS_Communication_Fault
BMS_Fault
PV_L1_BuckOverCurr_Fault(INT)
PV_L2_BuckOverCurr_Fault(INT)
OUT_L1_BuckOverCurr_Fault(INT)
OUT_L2_BuckOverCurr_Fault(INT)
PV1_OverVolt_Fault(INT)
PV2_OverVolt_Fault(INT)
BAT_OverVolt_Fault(INT)
OUT_OverVolt_Fault(INT)
BUS_OverVolt_Fault(INT)
PV1_OverCurr_Fault(INT)
PV2_OverCurr_Fault(INT)
BAT_OverCurr_Fault(INT)
